Flange Mount Filter Pump Motor Assembly


|
1
| | Motor,
1/2 HP, 60 Hz
|
1
|
A
|
|
2
| |
Seal kit
|
1
| A |
|
3
| |
5 GPM pump assembly
|
1
| B |
|
4
|
SC01-132
|
- Pump cover screw
|
1
| |
|
5
| |
- Pump cover
|
1
| |
|
6
| |
- Pump rotor
|
1
| |
|
7
|
171169
| -
Pump roller (set of 5)
|
1
| A |
|
8
| 162498 |
- O-ring
|
1
| B |
| 9 | N/A | Pump body not sold separately. Use 171168. | | |
| 10 | FP01-242 | Fitting, 1/2 NPT male to 45 flare male | 1 | |
| 11 | FP01-090 | Elbow, 1/2 NPT X 90° female, black iron | 1 | |
| 12 | FP02-062 | Nipple, 1/2 NPT X 1.75 in, black iron | 1 | |
| 13 | FP01-256 | Fitting, 12 SAE X 1/2 NPT | 1 | |
| 14 | 90506-001 | Check valve, SAE 12, 3 PSI | 1 | |
| 15 | FP01-254 | Elbow, 90 degree, 12 SAE, 45 flare | 1 | |
The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
