Cabinet Assembly

Item No.	Part No.	Description	Qty. per Door			Stocking Level
Item No.	Part No.	Description	900	903	904
1	25687	Retainer, 20 inch	8	4	-
2	25689	Retainer, 27.5 inch	8	-	-
2	25690	Retainer, 22.25 inch	-	4
3	25643	Door gasket	4	-	-	B
3	25793	Door gasket	-	2	-	B
3	77768	Door gasket	-	-	2	B
4	27895	Air duct, upper, 3.75 in. spacing	2	-	-
4	52345	Air duct, upper, 3.25 in. spacing (15 tray)	2	-	-
5	27811	Air duct, lower, 3.75 in. spacing	2	-	-
5	52346	Air duct, lower, 3.25 in. spacing (15 tray)	2	-	-
6*	25957	Air duct	-	2	-
6*	70387	Air duct (for 903 units with flip doors)	-	2	-
6*	70032	Air duct, Pollo Campero	-	2	-
6*	153675	Air duct, KFC Australia	-	2	-
6*	80044	Air duct	-	-	2
7	25879	Water box assembly complete	1	1	1	B
8	-25646	-Wiper for water box	1	1	1
9	-25685	-Handle for water box	1	1	1
10	-LW02-005	-Lockwasher, internal #10	A/R	A/R	A/R
11	-NS03-030	-Acorn nut, #10-32	A/R	A/R	A/R
12*	71478	Water box assembly complete (for 903s w/ flip doors)	-	1	-	B
13*	25670	Water box cradle	1	1	1
14	27155	Caster, 5 in. swivel	2	2	-
14	27154	Caster, 5 in. swivel, w/ brake	2	2	-
14	18645	Caster, 2.5 in. swivel	2	2	-
14	18646	Caster, 2.5 in. swivel, w/ brake	2	2	-
14	68804	Caster, 5 in. swivel CE	2	2	-
14	68803	Caster, 5 in. swivel, w/ brake CE	2	2	-
14	19904	Caster, 2 in. swivel	-	4	-
15	14647	Kit-4 inch leg (set of 4 legs)	-	A/R	-
16	-68938	-4 in. adjustable leg	-	A/R	-
17	-26120	-Adjustable foot	-	A/R	-
18*	27149	Door stop	4	2	2
19	LW01-002	Lockwasher, split, 1/4 in.	8	8	8
20	SC01-104	Hex screw, 1/4-20 x 1-1/2 in.	8	8	8
21	27944	Cap screw, #8	10	10	10
22	LW02-006	Lockwasher, internal, #8	10	10	10
23	NS01-008	Hex nut, #8-32	10	10	10
24*	28207	Cover plate (only for no water pan option)	A/R	A/R	A/R
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown

The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
