Gas Assembly

Item No.	Part No.	Description	Qty.	Stocking Level
1	MM10014407	Lift magnet, 120 V	1	C
2	MM10013836	Lift magnet connector	1
3	N/A
4	MM10017377	Ignition box, digital, 110 V	2	B
5	MM10014476	Solenoid gas valve, 1/2 inch, 1100 V	2	B
7	MM201230	Gas orifice, 580	2
8	MM211136	Ring seal, 15.5 X 24, 3 mm	2
9	MM116060	Catch nut, M3	12
10	N/A
11	MM202806	High limit, 10 & 20 pan	2	B
12	MM205310	Flange bracket with seal	4
13	MM102005	Hexagon screw, M4 X 30	4
14	MM102006	Hexagon screw, M4 X 12	2
15	MM116061	Catch nut, M5	16
16	MM201172	Gas burner connection 10.X	2
17	MM10037621	Ignitor kit - glow electric flame sense	2	A
18	MM202606	Combustion blower, 110 V	2	B
19	MM201177	Flame sensor	2	A
20	MM911589	Ignitor and sensor plate	4
21	MM945484	Burner connection flange	2
22	MM211141	Flat ring seal, 62, 82, 1.5 mm	2
23	MM945489	Washer, 64 mm	2
24	MM10016866	Restriction flange	2
25	MM211142	Flat ring seal, 52 X 82, 1.5 mm	4
26	MM201182	Venturi mixed tube	2
29	MM205309	Bolt screw	2
30	MM211137	Ring seal, 15, 5 mm	2
31	MM120008	Washer	4
32	MM116063	Catch nut, M6	8
34	MM10014663	Motor, 6.X-20.X	2
37	MM101127	Hexagon screw, M4 X 8	8
38	MM121023	Serrated washer, 4.3 mm	18
39	MM203999	Ignition transformer, T2/3	2	B
40	MM120017	Washer, M4	4
41	MM101412	Side panel screw	4
44	MM205307	Gas line coupling	2
45	MM204591	Pipe connection, 3/4, 20.X	1
47	MM203835	Reduct for cable gland, M25	1
48	MM101403	Hexagon screw, M45 X 16	8
49	MM201178	Burner pipe, 49.5-147.8 mm	2
50	MM105115	Cylinder head cap screw, M4 X 12	6
51	MM204681	Shaft sealing washer	2
52	MM211084	Motor shaft seal	2
53	MM945661	Motor shaft washer	2
55	MM205308	Bow for intake fitting	2
58	MM045017	Flexible tube, 50 mm	1
59	MM113092	Hexagon nut, M8	8
60	MM10014580	Thermoswitch, 70° C off	1
61	MM202746	Thermoswitch, 50° C on, 16A	1
62	MM105008	Screw	4
63	MM116041	Lock nut, M3	4
