Hose Reel and Hand Shower Assembly

Item No.	Part No.	Description	Qty.	Stocking Level
1	MM113082	Hex nut, M4	2
2	MM120017	Washer, M4	4
3	MM101127	Hexagon screw, M4 X 8	4
4	N/A
5	MM10017616	Screwing hose, G1/2 inch I - 10/7	1
6	MM10017617	Hose reel fitting	1
7	MM10017618	Hose, PE, inner diameter 7 X 1.5	1
8	MM10017619	Lock ring	1
9	MM205293	Distributor, 2 X 3/4, 1/2 inch	1
10	MM204532	Mounting plate for solenoid valve	1
11	MM121023	Serrated washer, 4.3 mm	2
12	MM101412	Side panel screw	2
13	N/A
15	MM10017551	Tube carrier including hose	1
16	N/A
17	N/A
18	MM10019505	Hand shower without hose	1
19	MM203352	Snap through bearing, LD 50 mm	1
20	MM121033	Spring lock washer, 6 mm	2
