Water Supply Assembly
|
Item No. |
Part No. |
Description |
Qty. |
Stocking Level |
|---|---|---|---|---|
| 1 | MM935545 | Water supply pipe, gas 10.X | 1 | |
| 2 | MM10011097 | Flat ring seal, 10 X 14, 1 mm | 1 | |
| 3 | MM101127 | Hexagon Screw, M4 X 8 | 1 | |
| 4 | MM121031 | Spring lock washer, 4 mm | 1 | |
| 5 | MM120017 | Washer, M4 | 1 | |
| 6 | MM10011101 | Piping for water supply pipe | 1 | |
| 7 | MM10011098 | Flat seal, 58 X 22 mm | 1 | |
| 8 | MM120045 | Washer, 13 mm | 1 | |
| 9 | MM10011099 | Water supply pipe nut | 1 |
