Electronic High Limit Assembly
Serial Numbers LG2507045 & Above
Item No. |
Part No. |
Description |
Qty. | Stocking Level |
|---|---|---|---|---|
| 1 | 175915-006 | Dual high-limit control, 100-240V, 575°, SVC Pack | A/R | A |
| * | NS02-002 | Nut, hex, keps #6-32 (high limit mounting nut) | A/R | |
| 2 | 140999 | High limit probe kit, full vat | A/R | A |
| 2 | 140464 | High limit probe kit, split vat | A/R | A |
| 3 | 157360 | High limit reset switch | A/R | A |
| 4* | 150419 | High limit enclosure (for single well units only) | 1 | |
| 4 | 187600 | High limit enclosure (for 2, 3 & 4 well units only) | 1 | |
| 5 | 167367 | Wire shield (for 2, 3 & 4 well units only) | 1 | |
| 6 | EF02-151 | Snap bushing, thin .875 | 1 | |
| 7 | EF02-131 | Clamp, 1/2 ID X 3/8 wide (for 2, 3 & 4 well units only) | 6 | |
| 8 | 151142 | High limit switch decal (for 2, 3 & 4 well units only) | 1 | |
| 9* | 18111 | Conduit connector, straight (for single well units only) | 1 | |
| 10* | 153225 | Reset switch bracket (for single well units only) | 1 | |
| 11* | 18107 | Conduit connector, 90° (for single well units only) | 1 | |
| 12 | 74639-003 | Edge grommet, 3 inch (for 2, 3 & 4 well units only) | 1 | |
| 13 | 74638-004 | Edge grommet, 1.35 inch | 1 | |
| 14 | EC02-005 | Terminal, straight, 2 blade adapter | A/R | |
| Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown A/R = As Required | ||||
Wire Harnesses
Part No. |
Description | Qty. | Notes |
|---|---|---|---|
| 154651-001 | HL & TC jumper, full well 1 | A/R | TC-2A, TC-2B, red & white wires |
| 154651-002 | HL & TC jumper, full well 2 | A/R | TC-4A, TC-4B, red & white wires |
| 154651-003 | HL & TC jumper, full well 3 | A/R | TC-6A, TC-6B, red & white wires |
| 154651-004 | HL & TC jumper, full well 4 | A/R | TC-8A, TC-8B, red & white wires |
| 159654 | HL module power, RHLP | A/R | RHLP, black wire |
| 159655 | HL module power, LHLP | A/R | LHLP, black wire |
| 159656 | HL switch jumper | A/R | HLPJ, black wire |
| 159915-001 | HL & TC jumper, well 1 | A/R | TC-1A, TC-1B, TC-2A, TC-2B, red & white wires |
| 159915-002 | HL & TC jumper, well 2 | A/R | TC-3A, TC-3B, TC-4A, TC-4B, red & white wires |
| 159915-003 | HL & TC jumper, well 3 | A/R | TC 5A, TC-5B, TC-6A, TC-6B, red & white wires |
| 159915-004 | HL & TC jumper, well 4 | A/R | TC-7A, TC-7B, TC-8A, TC-8B, red & white wires |
| 187711-200 | HL power & signal (used on FF, FS & SF configurations) | A/R | HLP, HLPN, RHL1, RHL2, RHL3, RHL4, red, white & black wires |
| 187711-300 | HL power & signal (used on FFF, FFS, FSS, SFF, SSF & SSS configurations) | A/R | HLP, HLPN, RHL1, RHL2, RHL3, RHL4, RHL5, RHL6, red, white, black & blue wires |
| 187711-400 | HL power & signal (used on FFFF, FFFS, FFSS, FSSS, SFFF, SSFF, SSSF & SSSS configurations) | A/R | HLP, HLPN, RHL1, RHL2, RHL3, RHL4, RHL5, RHL6, RHL7, RHL8, red, white, black, blue & brown wires |
| 187712-200 | HL power & signal (used on FF, FS & SF configurations) | A/R | HLP-1, HLPN-1, HLPN-2, HLPN-3, HLPN-4, RHL1-1, RHL2-1, RHL3-1, RHL4-1 red, white & black wires |
| 187712-300 | HL power & signal (used on FFF, FFS, FSS, SFF, SSF & SSS configurations) | A/R | HLP-1, HLPN-1, HLPN-2, HLPN-3, HLPN-4, HLPN-5, HLPN-6, RHL1-1, RHL2-1, RHL3-1, RHL4-1, RHL5-1, RHL6-1, red, white, black & blue wires |
| 187712-400 | HL power & signal (used on FFFF, FFFS, FFSS, FSSS, SFFF, SSFF, SSSF & SSSS configurations) | A/R | HLP-1, HLPN-1, HLPN-2, HLPN-3, HLPN-4, HLPN-5, HLPN-6, HLPN-7, HLPN-8, RHL1-1, RHL2-1, RHL3-1, RHL4-1, RHL5-1, RHL6-1, RHL7-1, RHL8-1, red, white, black, blue & brown wires |
| 187713-100 | Left vat HL, SF (used on SF, SFF & SFFF configurations) | A/R | LHL1, LHL2 violet wires |
| 187713-200 | Left vat HL, SS (used on SS, SSF & SSFF configurations) | A/R | LHL1, LHL2, LHL3, LHL4 violet and yellow wires |
| 187713-210 | Left vat HL, FS (used on FS configuration) | A/R | LHL3, LHL4 yellow wires |
| 187713-300 | Left vat HL, SSS (used SSS, SSSF configurations) | A/R | LHL1, LHL2, LHL3, LHL4, LHL5, LHL6 violet, yellow & grey wires |
| 187713-310 | Left vat HL, FSS (used on FSS configuration) | A/R | LHL3, LHL4, LHL5, LHL6 yellow & grey wires |
| 187713-320 | Left vat HL, FFS (used on FSS configuration) | A/R | LHL5, LHL6 grey wires |
| 187713-400 | Left vat HL, SSSS (used on SSSS configuration) | A/R | LHL1, LHL2, LHL3, LHL4, LHL5, LHL6, LHL7 violet, yellow, grey & black wires |
| 187713-410 | Left vat HL, FSSS (used on FSSS configuration) | A/R | LHL3, LHL4, LHL5, LHL6, LHL7, LHL8 yellow, grey & black wires |
| 187713-420 | Left vat HL, FFSS (used on FFSS configuration) | A/R | LHL5, LHL6, LHL7, LHL8 grey & black wires |
| 187713-430 | Left vat HL, FFFS (used on FFFS configuration) | A/R | LHL7, LHL8 black wires |
| 187714-100 | Left vat HL, S (used on SF, SFF, SFFF configurations) | A/R | LHL1-1, LHL2-1 violet wires |
| 187714-200 | Left vat HL, SS (used on SS, SSF, SSFF configurations) | A/R | LHL1-1, LHL2-1, LHL3-1, LHL4-1 violet & yellow wires |
| 187714-210 | Left vat HL, FS (used on FS configuration) | A/R | LHL3-1, LHL4-1 yellow wires |
| 187714-300 | Left vat HL, SSS (used on SSS configuration) | A/R | LHL1-1, LHL2-1, LHL3-1, LHL4-1, LHL5-1, LHL6-1 violet, yellow & grey wires |
| 187714-400 | Left vat HL, SSSS (used on SSSS configuration) | A/R | LHL1-1, LHL2-1, LHL3-1, LHL4-1, LHL5-1, LHL6-1, LHL7-1, LHL8-1 violet, yellow, grey & black wires |
| 187714-410 | Left vat HL, FSSS (used on FSSS configuration) | A/R | LHL3-1, LHL4-1, LHL5-1, LHL6-1, LHL7-1, LHL8-1 yellow, grey & black wires |
| 187714-420 | Left vat HL, FFSS (used on FFSS configuration) | A/R | LHL5-1, LHL6-1, LHL7-1, LHL8-1 grey & black wires |
| 187714-430 | Left vat HL, FFFS (used on FFFS configuration) | A/R | LHL7-1, LHL8-1, black wires |
| Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown A/R = As Required | |||
