Split Vat Components and Heating Elements
Exterior Components
| Part No. | Description | Qty. | Stocking Level | |
|---|---|---|---|---|
| 1* | 140713 | Split vat replacement kit | 1 | |
| 2.1* | 140714 | Temperature probe kit, 2 in. (rear vat) | 2 | A |
| 2.2* | 140637 | Level probe kit, 2-1/2 in. (front vat) | 2 | A |
| 3 | 185034 | - Compression fitting, 3/16 in. | 4 | |
| 4 | 159820 | Check valve fitting | 2 | A |
| 5 | 140244 | Drain valve kit, without motor | 2 | B |
| 5* | 84415 | - Drain valve O-ring only | 2 | |
| 6 | 86157 | Drain valve motor only | 2 | B |
| 7 | 95704-007 | Drain tube | 2 | |
| 8 | MS01-315 | Trough gasket clamp | 2 | |
| 9 | 161216 | Trough cover plate | 1 | |
| 10* | NS04-004 | Trough cover plate flanged locknut | 4 | |
| 11* | 161771 | Trough cover plate gasket | 1 | |
| 12 | 172936-002 | Split vat trough gasket service pack | 1 | |
| 13.1* | 172933 | 1 Vat drain trough service pack | 1 | |
| 13.2* | 172932 | 2 Vat drain trough service pack | 1 | |
| 13.3* | 172931 | 3 Vat drain trough service pack | 1 | |
| 13.4* | 172930 | 4 Vat drain trough service pack | 1 | |
| 14* | 175881 | Pot insulation, front to rear, foil backed | A/R | |
| 15* | MS04-001 |
Aluminum foil tape, 2.83 inch wide (used on foil backed insulation) |
A/R | |
| 16* | 163376 | Pot insulation, between vats, 1/2 inch | A/R | |
| 17* | 163379 | Pot insulation, between vats, 2 inch | A/R | |
| Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown |
||||
Interior Components
| Part No. | Description | Qty. | Stocking Level | |
|---|---|---|---|---|
| 1 | 180682-001 | Left split vat heating element service pack, 7 kW, 208 VAC, 3 Wire, 3+G | 1 | B |
| 1 | 180682-002 | Left split vat heating element service pack, 7 kW, 230/400 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-005 | Left split vat heating element service pack, 7 kW, 220/380 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-006 | Left split vat heating element service pack, 7 kW, 240/415 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-008 | Left split vat heating element service pack, 7 kW, 230 VAC, 3 Wire, 3+G | 1 | B |
| 1 | 180682-009 | Left split vat heating element service pack, 7 kW, 240 VAC, 3 Wire, 3+G | 1 | B |
| 1 | 180682-010 | Left split vat heating element service pack, 8.5 kW, 208 VAC, 6 Wire, 3+G | 1 | B |
| 1 | 180682-011 | Left split vat heating element service pack, 8.5 kW, 230/400 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-014 | Left split vat heating element service pack, 8.5 kW, 220/380 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-015 | Left split vat heating element service pack, 8.5 kW, 240/415 VAC, 4 Wire, 3NG | 1 | B |
| 1 | 180682-017 | Left split vat heating element service pack, 8.5 kW, 230 VAC, 6 Wire, 3+G | 1 | B |
| 1 | 180682-018 | Left split vat heating element service pack, 8.5 kW, 240 VAC, 6 Wire, 3+G | 1 | B |
| 2 | 180683-001 | Right split vat heating element service pack, 7 kW, 208 VAC, 3 Wire, 3+G | 1 | B |
| 2 | 180683-002 | Right split vat heating element service pack, 7 kW, 230/400 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-005 | Right split vat heating element service pack, 7 kW, 220/380 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-006 | Right split vat heating element service pack, 7 kW, 240/415 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-008 | Right split vat heating element service pack, 7 kW, 230 VAC, 3 Wire, 3+G | 1 | B |
| 2 | 180683-009 | Right split vat heating element service pack, 7 kW, 240 VAC, 3 Wire, 3+G | 1 | B |
| 2 | 180683-010 | Right split vat heating element service pack, 8.5 kW, 208 VAC, 6 Wire, 3+G | 1 | B |
| 2 | 180683-011 | Right split vat heating element service pack, 8.5 kW, 230/400 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-014 | Right split vat heating element service pack, 8.5 kW, 220/380 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-015 | Right split vat heating element service pack, 8.5 kW, 240/415 VAC, 4 Wire, 3NG | 1 | B |
| 2 | 180683-017 | Right split vat heating element service pack, 8.5 kW, 230 VAC, 6 Wire, 3+G | 1 | B |
| 2 | 180683-018 | Right split vat heating element service pack, 8.5 kW, 240 VAC, 6 Wire, 3+G | 1 | B |
| 3 | 159882 | Split vat rack | 2 | |
| 4 | 140773 | Probe guard replacement service pack | 6 | |
| 5 | 180684 | Oil diverter cover service pack | 2 | |
| 5* | SC01-286 | - Screw, #8-32 x .75, PH, FHD, SS | A/R | |
| Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown |
||||
Heating Element Components
| Part No. | Description | Qty. | Stocking Level | |
|---|---|---|---|---|
| 1-2 | - |
Split vat heating element service pack components |
- |
- |
| 3 | 76948 | - Pivot block o-ring | 2 | |
| 4 | 86306 | - Outer pivot block gasket | 1 | |
| 5 | 86308 | - Inner pivot block gasket | 1 | |
| 6 | 180686 | - Split vat element brackets service pack | 1 | |
| 6* | -169655 | - Element bracket, foot, split | 1 | |
| 6 | -177557 | - Element brace, split | 1 | |
| 6* | -78499 | -Spreader strap | 4 | |
| 6* | -SC04-024 | - Screw #8-32 X 3/8 Hex Hd SS | 5 | |
| 7 | 180687 | - High limit RTD service pack | 1 | |
| 8 | 86303 | Outer pivot block | 2 | |
| 9 | 86305 | Inner pivot block | 1 | |
| 10 | 83038 | Element tilt switch arm | 1 | |
| 11* | 83096 | Element tilt switch | 2 | A |
| NOTE - Left / Right split vat element orientation as viewed from fryer control panel Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown |
||||
