Element Assembly

Item No.

Part No.

Description

Qty.

Stocking Level


78484-001

Heating element, 208 VAC, 7 kW

2 full / 1 split

B


78484-002

Heating element, 230 VAC, 7 kW

2 full / 1 split

B


78484-003

Heating element, 480 VAC, 7 kW

2 full / 1 split

B


78484-004

Heating element, 200 VAC, 7 kW

2 full / 1 split

B


78484-005

Heating element, 220 VAC, 7 kW

2 full / 1 split

B


78484-006

Heating element, 240 VAC, 7 kW

2 full / 1 split

B

Full Vat Element Assembly Detail

Item No.

Part No.

Description

Qty.

Stocking Level

1

SC01-076

Screw, #8-32 X 1/4, CT, THD, SS

2/vat

2

75819

Front capillary plate

1/vat

3

75818

Rear capillary plate

1/vat

4

SC01-074

Screw, #10-32 X 1/2, CT THD, SS

4/vat

5

74209

Element pivot housing

1/vat

6

82459

Element pivot housing, right full

1/vat

7

78499

Spreader strap

6/vat

8

N/A

High limit reset kit

1/vat
8 77285 - High limit - 425 1/vat
8 77147 - Stud assembly pivot hi limit bracket 1/vat
8 96320 - Weld assembly hi limit reset pin 1/vat
8 96322 - Weld assembly hi limit mounting bracket 1/vat
8 150329 - Spring-.043 X .200 X .750 1/vat
8 RR01-007 - Ring-retaining 3/16 shaft 1/vat

9

78896

Ground and wire mounting stud assembly

1/vat
10

78614

Front high limit guard, full

1/vat


11

78615

Rear high limit guard, full

1/vat


12

78494

Spreader weld assembly, full

2/vat


13

SC04-003

Screw, #8-32 X 3/8, CT, SS

12/vat


14 82261 Hub gasket 2/vat
15*

OR01-004

O-ring (fits on element against items 5 & 6)

2/element

A
Recommended Parts: A = Truck Stock; B = Dist. Stock

* = Not Shown

Split Vat Element Assembly

Item No. Part No. Description Qty. Stocking Level
1 SC01-076 Screw, 8-32 x 1/4 inch 2/vat
2 75819 Front capillary plate 1/vat
3 75818 Rear capillary plate 1/vat
4 SC01-074 Screw, 10-32 x 1/2 inch 2/vat
5 74209 Element pivot housing 1/vat
6

N/A

High limit reset kit

1/vat


6 77285 - High limit - 425 1/vat
6 77147 - Stud assembly pivot hi limit bracket 1/vat
6 96320 - Weld assembly hi limit reset pin 1/vat
6 96322 - Weld assembly hi limit mounting bracket 1/vat
6 150329 - Spring-.043 X .200 X .750 1/vat
6 RR01-007 - Ring-retaining 3/16 shaft 1/vat
7 78780 High limit mounting bracket 1/vat
8 78499 Spreader strap 4/vat
9 78601 Front high limit guard 1/vat
10 78602 Rear high limit guard 1/vat
11 78617 Split spreader weld assembly 2/vat
11 79324 Split spreader weld assembly, fish vat 2/vat
12 SC04-003 Screw, 8-32 x 3/8 inch 6/vat
13 82261 Pivot hub gasket 1/vat B
14* OR01-004 O-ring (fits on element against items 5 and 6) 2/element A
Recommended Parts: A = Truck Stock; B = Dist. Stock

* = Not Shown

ELMNT = Heating Element
