Door Assembly

LVG-200 Door Assembly

Door Assembly No.	Top Hinge (Door)	Bottom Hinge (Door)	Left Hinge (Frame)	Right Hinge (Frame)	Bushing
83774	83903	83904	85409	- - - - -	39752
86382	83904	83903	- - - - -	85408	39752
83727	83904	83903	- - - - -	85408	39752

LOV door assembly

Item No.	Part No.	Description	Qty.
1	SC04-001	Screw, #8-32 x 3/8 in, CT	4
2	83904	Door hinge stud assembly, right	1
3	83903	Door hinge stud assembly, left	1
4	SC04-003	Screw, #8-32 x 3/8 in, CT, HPD, SS	2
5	41836	Door handle	1
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown

The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
