Chassis Exterior

Item No.	Part No.	Description	Qty. 52X	Qty. 53X	Stocking Level
1	182492	Upper rear shroud, 2 well	1	0
1	182385	Upper rear shroud, 3 well	0	1
2	83370-2	"Caution Hot" label, UL, Mylar	1	1
3	183254	Vat cover	2	3
4	182373	Control shroud, 2 well	1	0
4	182332	Control shroud, 3 well	0	1
5	183992	Wi-Fi cover decal	1	1
6	52224	Power switch	2	3	A
7	157360	High limit reset switch	2	3	A
8	EF02-125	Push button reset breaker	4	6	B
9	EF02-104	Fuse holder, 20 amp, 250 VAC	1	1	A
10	182590	Lower front cover, 2 well	1	0
10	182344	Lower front cover, 3 well	0	1
11	182351	Front panel bracket	2	2
12	184459	Filter pan latch bracket	1	1
13	SC01-057	Head screw, hex, 1/4-20 x 1/2 -Filter pan latch screw	2	2
14	17612	1 x 1 1/2 leg insert	4	4
15	185966	Caster, 3.5 inch, swivel, w/ end brake, front	2	2	C
16	77679	Caster, 4 inch, swivel, w/o brake, rear	2	2	C
17	182494	Side panel	2	2
18	182587	Rear cover, 2 well	1	0
18	182448	Rear cover, 3 well	0	1
19	182588	Breaker cover, 2 well	1	0
19	182543	Breaker cover, 3 well	0	1
20	182586	Breaker shield, 2 well	1	0
20	182387	Breaker shield, 3 well	0	1
21	184775	Power cord anchor bracket	2	2
22	183676	Oil manifold support bracket	2	2
23	182392	Rear electrical box mounting flange bracket	4	4
24	182318	Wire raceway	4	4
25*	74638-007	Edge grommet .029 - .045 x 3.00	16	16
26	162660	Push mount, 50 lbs, 6 inch wire tie	32	32
27	184554	Drain actuator harness bracket	2	2
28	183334	Base deck, 2 well	1	0
28	183424	Base deck, 3 well	0	1
29*	SC03-001	TEK screw, #10 x 1/2 PH, PHD -Base deck screw	13	13
30*	NS04-005	Serrated, flanged locknut, 1/4-20 -Base deck nut	17	17
31	184563	Drain reed switch cover, 2 well	1	0
31	184568	Drain reed switch cover, 3 well	0	1
32	183941	Drain reed switch bracket, 2 well	1	0
32	183932	Drain reed switch bracket, 3 well	0	1
33	184277	Drain reed switch shield, 2 well	1	0
33	184276	Drain reed switch shield, 3 well	0	1
34	SC03-001	TEK screw, #10 x 1/2 PH, PHD -Drain reed switch cover & shield screw	3	3
35	183287	Trough support bracket	1	1
36	NS04-005	Serrated, flanged locknut, 1/4-20 -Trough support bracket nut	2	2
37	183193	Filter pan rail, outer	2	4
38*	183555	Filter pan rail, middle	1	0
39	185186	Air flow block bracket, 2 well	1	0
39	185183	Air flow block bracket, 3 well	0	1
40	174662	Rear shroud mounting plate	2	2
41	182347	Control shroud brace	1	2
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown

The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
