JIB (ATO) System

Item No.	Part No.	Description	Qty. 52X	Qty. 53X	Stocking Level
1	161003-002	JIB (ATO) Pump, 230V	1	1	A
2*	184489-001	Harn-JMF, JM, DSP-L - 18AWG - JIB (ATO) pump harness, 2 well	1	0
2*	184489-002	Harn-JMF, JM DSP-L - 18AWG - JIB (ATO) pump harness, 3 well	0	1
3	163895	Straight quick disconnect x 15/16-16, 45° flare	2	2
4*	163877-100	Braided oil line, 3/4 in (19mm) OD, 10 in (26cm) long	2	2	B
5	183411	12 SAE x 1 1/16 ferulok elbow	1	1
6	159820	Check valve fitting, 12 SAE x 15/16-16, 45° flare	1	1	B
7*	163877-120	Braided oil line, 3/4 in (19mm) OD, 12 in (31cm) long	1	1	B
8	183383-002	ATO plug & play assembly	1	1
9	-164642	Straight 12 SAE x 15/16-16 UN, 45° flare	4	4
10	-RR01-008	Retaining ring, 1 1/2 inch shaft, SS	1	1
11	-164668	2.125 OD x 1.520 ID, washer for plug & play	1	1
12	-183604	ATO plug & play bracket	1	1
13	-180676	ATO plug & play kit	1	1
14	183371	ATO box complete assembly	1	1
15	183372	ATO box lid assembly	1	1
16	172926	ATO box lid gasket	1	1
17	183368	ATO box	1	1
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown
