Rear Electrical System

Item No.	Part No.	Description	Qty. 52X	Qty. 53X	Stocking Level
1	65073	Contactor, heat, Square D, 24 VAC	8	12	A
2	183523	3 pole terminal block	4	6	C
3	183840-002	Outer well current sensor harness	2	2
4	183840-003	Inner well current sensor harness	0	1
5	184933	Protection breaker	4	6	A
6	184934	Auxiliary contactor breaker	4	6	A
7	40761	End stop din 3	6	9
8	182328	3 pole power distribution block	2	3
9	SC01-133	Screw, #8-32 x 5/8 inch PH THD -PWR distribution block screw	8	12
10	183522	Bussbar	4	6
11	184446	Din rail, 8.5 inches long	2	3
12	182322	Rear electrical components mounting plate	2	3
13	NS04-004	Serrated, flanged locknut, 10-24 -Mounting plate nut	10	15
14	184664-160	Wire duct, 2 x 2, 16 inch	1	2
13	NS04-004	Serrated, flanged locknut, 10-24 -Wire duct nut	2	2
15	184660-160	Wire duct, 2 x 1, 16 inch	1	2
13	NS04-004	Serrated, flanged locknut, 10-24 -Wire duct nut	4	4
16	182489	Rear electrical components shroud, 2 well	1	0
16	182297	Rear electrical components shroud, 3 well	0	1
13	NS04-004	Serrated, flanged locknut, 10-24 -Electrical component shroud nut	16	16
17	183685	Power cord bracket	2	3
13	NS04-004	Serrated, flanged locknut, 10-24 -PWR cord bracket nut	8	12
18*	186745	Power cord & plug assembly	2	3
19*	181601	Power cord wall plate & tether bracket assembly	A/R	A/R
20*	-181358	Power cord tether bracket	A/R	A/R
21*	-181366	Power cord wall plate	A/R	A/R
22	EF02-142	Snap bushing, 1.375 ID	6	6
23	EC01-030	Terminal lug, #4 wire, 1/4 inch bolt	2	3
24	NS04-005	Serrated, flanged locknut, 1/4-20 -Terminal lug nut	2	3
25	EF02-138	Snap bushing .687 ID x .953 OD	8	12
26	79525	Lever nut, 3 conductor connector	A/R	A/R
27	79526	Lever nut, 5 conductor connector	A/R	A/R
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown A/R = As Required

The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
