Front Electrical System
| Item No. | Part No. | Description | Qty. | Stocking Level |
|---|---|---|---|---|
| 29509 | 24 VAC primary contactor | 1 | A | |
| NS02-005 |
Keps nut, #6-32, hex (Primary contactor nut) |
4 | ||
| 65073 | 24 VAC heat contactor | 1 | A | |
| NS02-005 |
Keps nut, #6-32, hex (Heat contactor nut) |
2 | ||
| 184416 | Heat contactor mounting plate | 1 | ||
| NS02- 005 |
Keps nut, #6-32, hex (Heat contactor mounting plate nut) |
3 | ||
| 84134 | Transformer, 24V/208V, 75VAC | 1 | A | |
| NS02-005 |
Keps nut, #6-32, hex (Transformer mounting nut) |
2 | ||
| EF02-125 | Push button reset breaker | 2 | A | |
| EF02-104 | Fuse holder, 20A, 250V | 1 | A | |
| FA52-005 | Time delay fuse, 0.5 amp | 1 | A | |
| 157360 | High limit reset switch | 1 | A | |
| 175915-006 | Dual high-limit control, 100-240V, 575°, SVC Pack | 2 | A | |
| NS02-005 |
Keps nut, #6-32, hex (High limit mounting nut) |
4 | ||
| ME90-008 | Relay, 12 VDC, 30A | 1 | A | |
| NS02-005 |
Keps nut, #6-32, hex (Relay mounting nut) |
2 | ||
| 140936 | Power supply & THD LKG kit | 1 | A | |
| 181699 | Front electrical component shroud | 1 | ||
| SC03-005 |
Tek screw, #8 x 1/2 PH, PHD (Front electrical component shroud screw) |
5 | ||
| 167693 | Wire guard | 1 | ||
| SC03-005 |
Tek screw, #8 x 1/2 PH, PHD (Wire guard screw) |
1 | ||
| MS01-614 | Cushioned wire loop | 1 | ||
| SC03-001 |
Tek screw, #10 x 1/2 PH, PHD (Cushioned wire loop screw) |
1 | ||
| 183557 | Electrical component shroud insulation | 1 | ||
| WA02-001 | Insulation washer | 2 | ||
| * | 16303 | Countertop insulation | 1 | |
| EF02-069 | Snap bushing, 15/16 | 1 | ||
| EF02-014 | Strain relief, 1 inch, squeeze | 1 | ||
| EF02-101 | Conduit connector, 1 inch, flex | 1 | ||
| 183840-001 | Current sensor harness | 1 | A | |
|
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown A/R = As Required |
||||
