Lid & Crossarm Assembly

Item No.	Part No.	Description	Qty.	Stocking Level
1	182530-101	Lid w/ crossarm SVC pack	1	C
2	182528-101	Crossarm SVC pack	1
3	SC01-083	Lid cover screw	4
4	16133	Lid retaining hook	2
5	SC06-027	Retaining hook screw	4
6	16166	Lid spring & pin retainer	1
7	SC06-010	Lid spring & pin retainer screw	1
8	16165	Return spring	1
9	16164	Locking pin	1
10	16163	Seat ball	1
11	63729	Lid liner assembly	1
12	16120	Lid gasket	1	A
13	16199	Latch spring kit	1	A
14	33480	Latch spring	1	A
15	16198	Spacer	2
16	16197	Latch pin	1
17	16116	Lid latch	1
18	16102	Latch knob	1
*	16126	Latch stud	1
19	16121	Tru-arc latch ring	2
20	16137	Retaining pin knob	1
21	16138	Knob roll pin	1
22	16112	Lid hinge assembly	1
23	SC01-081	3/8-24 x 3/4 hex head bolt	4
24	LW01-010	3/8 split ring lockwasher	4
25	16110	Lid hinge pin	1	B
26	186381	Lid hinge spring	1	A
27	29587	Spring cover	1
28	14960	Spring loading tool kit	A/R
29	16111	Tru-Arc retainer ring	2
30	16136	Retaining pin spring	1
31	16135	Retaining pin cover	1
32	16102	Spindle knob (red)	1
33	16101	Spindle knob (black)	3
34*	36099	Danger decal	1
35*	16181	Lid operating instructions label	1
36*	16156	3/8-24 x 3/8 hex socket screw (Used in crossarm locking collar)	2
Recommended Parts: A = Truck Stock; B = Dist. Stock * = Not Shown

The parts descriptions listed have been modified to reduce mis-ordered parts. Be aware when ordering, the part description may differ. To verify the correct part when ordering, ensure the part number matches the part number listed here.
